PVC Coated Welded Wire Mesh by QingFa is the only wire mesh fabric in the world specifically engineered for ocean use; designed to withstand the harshest sub-sea conditions. PVC Coated Welded Wire Mesh is manufactured from high-grade premium steel that is hot-dip galvanized after welding with a thick layer of zinc that completely surrounds the weld to prevent the steel from corroding. The wire is then covered with our proprietary marine grade PVC coating that is fuse-bonded to the wire forming a protective layer that adheres to the wire and will not peel or strip in salt water environments. PVC Coated Welded Wire Mesh has also been proven to resist algae and fouling especially when used for aquaculture applications.
PVC Coated Welded Wire Mesh set the industry standard for durable, reliable and top performing marine wire mesh.
PVC Coated Welded Wire Mesh Advantages:
Dependable Performance
Specifically designed and manufactured using advanced galvanizing and PVC coating methods to maximize durability and longevity in the harshest marine environments.
Multifunctional Marine Uses
Available in a variety of patterns that can be easily fabricated into numerous configurations for traps, pots, creels, pens and trays that are designed for use in sub-sea or fresh water environments.
Lower Cost of Ownership
The corrosion resistant protective coating does not break, peel, strip or crack, reducing the need for costly and frequent repairs and replacements
Made in the China.
It is well known that Anping County is the home of wire mesh.
Engineered and manufactured in Massachusetts by a local lobster-man who knows the importance of using high quality marine grade wire mesh in harsh marine environments.
Mainly used in: Oyster＆Shellfish Trays,Fish Traps,Conch＆Whelk Traps, Crab Posts, Lobster Traps, Aquaculture Pens and so on......
Standard Roll Sizes
Custom cut panels also available
Spacing Cross Wires | Spacing Line Wires | Wire Gauge | Nominal Wire Size | Approx Weight lbs/100 sq.ft | Patterns: |
1/2” | 1/2” | 16 | 0.0625 | 63 | Square |
1/2” | 1” | 16 | 0.0625 | 49 | Hexagonal |
1” | 1” | 16 | 0.0625 | 33 | Rectangular |
1” | 1” | 14 | 0.080 | 57 | |
1.5” | 1.5” | 12.5 | 0.099 | 59 | Colors: |
3” | 3” | 11 | 0.120 | 45 | Black |
2” | 4” | 11 | 0.120 | 49 | Green |
1.5” | 1.5” | 10.5 | 0.128 | 93 | Yellow |
4.5” | 4.5” | 8 | 0.162 | 47 | Blue |
Red | |||||
White |
Standard Hex Sizes
Size | width | length | Gauge | Appro-weight lbs/150 sq.ft |
1.5” | 24” | 150’ | 17.5 | 61 |
1.5” | 24” | 150’ | 17 | 68 |
Note: please be aware that hexagonal size is not welded, it is twisted, galvanized and then coated with our proprietary marine grade PVC.
The sizes and colors listed are those most commonly manufactured. Custom mesh sizes and colors are available by request. All weight are approximate. Mesh sizes are measured center to center of wire before coatings are applied.
